Pharmaceutical shipments

The RAP e2 is one of the most advanced temperature-controlled air cargo containers, designed for the extreme requirements of the pharmaceutical industry.
Having performed more than 23,000 real life pharmaceutical shipments, the RAP e2 container has proven its robustness and can easily carry five Euro pallets or four US pallets.

With an insulated container shell, electric heating and compressor cooling system and enhanced air circulation system, the RAP e2 maintains any set temperature between ±0 and +25 °C. In nearly any ambient condition along global shipping routes, it can maintain temperatures in the +2 to +8 °C range or controlled room temperature (+15 to +25 °C) range.

The RKN e1 is a one-pallet size container. Based on a second-generation active temperature control system, it uses compressor cooling and electric heating technology to meet the requirements of the pharmaceutical industry for smaller shipments.

The RKN e1 container maintains product temperatures in the +2 to +8 °C range, controlled room temperature (+15 to +25 °C) range or at any chosen set temperature between ±0 to +25 °C.

It has an insulated container shell, enhanced air circulation, electric heating and compressor cooling, as well as one energy source and batteries that can be recharged at standard AC power connection points. The RKN e1 container also offers data-logging functionality.

The Envirotainer RAP t2 container provides accurate and reliable protection for large shipments of temperature-sensitive products.

With an external dimension of 3170mm (L) x 2230mm (W) x 1620mm (H), the RAP is the largest container in the Envirotainer fleet. The RAP can only be forklifted when empty and is most commonly handled with roller beds.

The Envirotainer RAP t2 container features Envirotainer’s proven dry-ice-based active temperature control system and enables air transportation of both frozen and chilled product.

The Envirotainer RKN t2 container provides accurate and reliable protection for shipments of temperature-sensitive products.

With an external dimension of 2000mm (L) x 1535mm (W) x 1620mm (H), the RKN is the medium-size container in the Envirotainer fleet. The RKN can be forklifted.

The Envirotainer RKN t2 container features Envirotainer’s proven dry-ice-based active temperature control system and enables air transportation of both frozen and chilled products.

The RKN is the only compressor-driven refrigeration unit with precise temperature management of +4°C to +25°C . The robust insulation and thermal capabilities will withstand extended hold times and delays in transit.

The battery life is over 100 hours at +25°C and, because there is no dry ice, there are no special handling charges or charges for hazardous goods. In addition, the data tracking device monitors and verifies the payload temperature to aid regulatory compliance and data is easily downloadable via a USB.

The CSafe RKN is certified by the FAA, EASA, Transport Canada, Hong Kong CAD, Irish Aviation Authority and Australian CASA.

The CSafe RAP is the latest innovation in high-performing temperature controlled containers that combines innovative heating and compressor-driven cooling technologies with advanced VIP insulation to eliminate the risks associated with extreme ambient conditions (-30°C to +54°C) and long-duration shipments.

User-selectable temperature set points from +4°C to +25°C in 1°C increments, with a battery run time of up to 120 hours.

Automated data from 10 temperature sensors is available to download to a USB directly from the container.

The CSafe RAP is certified by the FAA, EASA, Transport Canada, Hong Kong CAD, Irish Aviation Authority and Australian CASA.

With quadruple redundancy for all critical components, the DoKaSch Opticooler RAP container reliably controls temperatures within the range of +2°C to +30°C.

Its touchscreen control panel makes it easy to use and it’s also cost-effective; with space for up to five Euro pallets or four US pallets.

With an extremely large battery capacity, highly advanced compressor technology and integrated CPU, the Opticooler outperforms all comparable units. The battery charging time is between two to four hours and the container does not require dry ice.

The Dokasch Opticooler RKN is reliable, cost-effective and user-friendly, with a large battery capacity, advanced compressor technology and integrated CPU, as well as a touchscreen control panel.

With space for one Euro pallet or one US pallet, the container reliably maintains temperatures within the range of +2°C to +30°C.

The battery charging time is between two to four hours and the container does not require dry ice.

The va-Q-tainer is a high-performing rental container which incorporates vacuum insulation and phase change materials to maintain the required temperature for more than five days. va-Q-tec’s Advanced Passive Alternative is delivered to you quality-checked and preconditioned, ready to LOAD & GO. The LOAD & GO Service simplifies the container handling during product loading and unloading as well as during transport, providing a reliable packaging solution for the most challenging trade lanes.

The single and double pallet solutions from va-Q-tec allow customers efficient use of payload space, preserving the efficacy, quality and value of pharmaceutical and biological products with one configuration for all seasons and hemispheres, not requiring power supply, fans or batteries.

Six temperature ranges from -40 to +25°C with PCM Elements, or up to -70°C with dry ice
Constant temperature, easy handling, low risk and high reliability
Performance at +2°C - +8°C from 120 to 230 hours

• Hybrid Containers from Skycell
• SkyCell’s hybrid containers combine hardware and software through the expertise of Swiss precision engineering. As safe, secure and sustainable solutions, they have been engineered to ensure lifesaving vaccines and medicines reach patients on time and in pristine condition
• SkyCell C/CRT containers
• The SkyCell C container maintains a temperature of +2°C to +8°C, while its CRT counterpart sustains +15°C to + 25°C respectively. Choose from 1 x EU-PAL or 1 x US-PAL (1500 model) to 2 x EU-PAL (2500 model). Each one is GDP certified, quality checked and delivered ready to use, with an average runtime of 202hrs (8.4 days), IoT sensors, and an audited performance of less than 0.1% temperature excursion rate. Plus, you can prolong the runtime by placing it in a cool environment (reefer truck or temperature controlled warehouse) where it can self-charge automatically.
• SkyCell 1500F containers
• For colder solutions and frozen transport, SkyCell has developed the F container. It is a safe, secure and sustainable container solution that doesn’t use dry ice.
• SkyCell’s frozen container offers a long independent runtime of -15°C to -30°C with a light weight of only 484kg. This is a strong feature as its lighter weight has a beneficial impact on the overall rate. With an average runtime of 120hrs, this can ensure that all medicines and vaccines are safeguarded throughout extended journeys. The F container is available as 1x EU-PAL or US-PAL.
• Engineered for cold transport, this frozen container protects pharma products from extreme temperatures, humidity, shock and vibrations
• SkyCell 1500DF containers
•  SkyCell’s innovative approach to deep frozen pharma protection, the DF container ensures biologics remain in pristine condition throughout the entire journey. For medicines and vaccines that need extremely low temperatures to be kept intact, this is the ideal solution.
• SkyCell’s deep frozen container ensures a steady temperature between -80° to -60°C and has an independent runtime of 120hrs. With containers sizes from 1 x US/EU-PAL, it features only 100kg of dry ice, significantly less than most deep frozen alternatives and is easy and safe to handle.
